The names a bit of a giveaway – this all-mountainelectric mountain bike is not for tame leisure rides.Mondraker’sCrusher will make easy work of challenging trails and demanding Enduro stages.

Designed to sit in-between the Crafty and Neat models a Crusher is a great option if you are looking to take your e-mtb to a wide range of locations. Comfortable enough to clock up big miles at a trail centrethough more than equipped to handlehitting feature-full bikepark lines.

The frame is engineered around Mondraker’s forward geometry,using a longer reach and shorter stem you will find the front wheel remains weighted at all times, the resulting consistent traction and stability will make you confident to keep speeds high.

Power is handled by the formidable Shimano EP801 motor and large capacity 720wh battery, more than enough juice for long days shredding.

The entry level Crusherhas a Fox 38 29 Float FIT GRIP EVOL Performance fork, SRAM GX Eagle chainset, SRAM DB8 brakes, an ONOFF Pija dropper seatpost (with between 125mm – 200mm of travel depending on frame size) and Maxxis Minion DHF/DHR II 2.6 EXO+ tyres.

SIZING –

• S: 160cm – 170cm
• M: 165cm – 180cm
• L: 175cm – 185cm
• XL: 185cm – 190cm+

Specifications::Crusher

• Discipline:All-Mountain

• Material:Carbon

• Front Travel: 160mm

• Rear Travel: 150mm

• Wheel Size: 29″

• Warranty: Lifetime (frame)

Frame – Crusher Stealth Air Carbon front triangle, Stealth Alloy rear triangle, e-Bike Optimized Zero Suspension System, 150mm travel, Forward Geometry, integrated internal non-removable battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 17mm axles, integrated dropout speed sensor, exclusive plastic motor covers.
Rear shock – Fox Float-X LV Performance, 205x65mm. Settings: compression 2 positions lever, low-speed rebound, air preload. Trunnion top mount, 25x10mm bottom bushings
Shock settings – medium compression, medium rebound, air volume spacer 0.2
Fork – Fox 38 29 Float FIT GRIP EVOL Performance, 160mm, e-bike tuned, tapered steerer tube, Boost 15x110mm axle, 44mm offset. Settings: 3 positions with micro adjust compression, low-speed rebound, air preload
Headset – Acros AZF-601 R1 Block Lock 120, ZS44/28.6 top, ZS56/40 bottom
Stem – Onoff Sulfur FG 30mm 0, 6061 forged alloy, 31.8mm barbore
Handlebar – Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9 backsweep, 5 upsweep, 31.8mm barbore
Grips – Onoff Desert, 1lock-on, 135mm
Seatpost – Onoff Pija dropper internal, diameter 31.6mm, 1X Remote lever with bearing, S size: 405×95-125mm, M size: 458×120-150mm, L size: 498×140-170mm, XL size: 558×170-200mm
Saddle – FIZIK Terra Aidon X5 145mm
Front brake – Sram DB8, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
Rear brake – Sram DB8, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
Brake lever – Sram DB8, tool reach adjust, lever pivot bushings
Rims – Mavic E-Deemax 29, 30mm internal width, welded, PFP, tubeless ready, 28 spokes
Spokes – Mavic J-bend double butted, contactless lacing
Front hub – Mavic, Boost 15x110mm, IS 6 bolts
Rear hub – Mavic, Boost 12x148mm, ID360 Ratchet system, IS 6 bolts, HG freehub
Front tyre – Maxxis Minion DHF 29×2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead
Rear tyre – Maxxis Minion DHR II 29×2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead
Crankset – Shimano Steps FC-EM600 ebike, 165mm
Rings – Sram X-Sync 2 Eagle 34T, alloy, narrow-wide, 104 BCD
Chain – Sram SX Eagle, 12s, Powerlock
Rear derailleur – Sram GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1
Shift levers – Sram Trigger NX Eagle, 12s, X-Actuation 1:1, single click
Cassette – Sram PG-1210, 11-50T, 12s
Derailleur hanger – Mondraker M068
Weight – 24,6 kg
Display – Shimano EN600
Motor – Shimano STEPS EP801
Battery – Simplo internal 720Wh G3
